Electrical Specifications:
Input Characteristics
Input Voltage: 175Vac to 264Vac
Nominal Input: 200Vac to 240Vac
Frequency range: 47Hz to 63Hz
Maximum input current: 15A max.
Leakage current: 0.5mA, @ 240Vac input
Rated power (220VAC): 1500W
Adjustable power range: 150- 1500W (continuous operation)
Maximum input voltage: 300Vac ( power supply can not be damaged)
Output Characteristics
Rated anode high voltage (typ.): 4~4.65KVdc
Rated anode output current: 430mA
Protection Function
AC RMS overvoltage protection: 275VAC
AC RMS undervoltage protection: 160VAC
Input overcurrent protection: 18A
Dependability
After 15,000 switching tests, the product should work normally.
Safety specifications
Power supply safety meets the following standards:GB4706.1/IEC60335.
Environmental Protection Directive
Products comply with PAHs, RoHS, REACH environmental directives.
insulation properties
Test voltage 500VDC/1 minute, AC side insulation impedance to ground is more than 100 megohm.
-
1000W_Air-cooled_Fixed Power MEP168P
1000W_Air-cooled_Fixed Power MEP168P
. Built-in high reliability design, dustproof and corrosion resistant
.176V to 264V input voltage output power range continuously adjustable from 250W to 1500W
. Built-in fault self-test, fault upload function
. Support multi-mode control, support for 0-5V analog and 485 communication digital two modes of power regulation -
MEP-4KW
MEP-4KW
. High Reliability Design with Built-in Multi-Protection
. Wide voltage range 600-3800W continuously adjustable
. Built-in Fault Detection Fault Upload Function
. Support multi-mode control -
Toshiba Air-cooled Magnetron
Toshiba Air-cooled Magnetron
-
1000W_Air-cooled_Adjustable power MEP168P
1000W_Air-cooled_Adjustable power MEP168P
